TPMS 胎压检测传感器实验台
TPMS 胎压检测传感器实验台 Tire Pressure Measurement Sensor high speed spin tester
Technical requirement
Climatic chamber
Temperature range : - 40 ℃ to + 180 ℃
Temperature Deviation: ≤ ± 2.0 K (According to JJF1101)
Temperature Uniformity in space: ≤ ± 1.0 K (According to JJF1101)
Temperature fluctuation in time: ≤ ± 0.5 K (According to JJF1101)
Heating: 12,0 K/min corresponding to IEC 60068-3-5
Cooling : 10,5 K/min corresponding to IEC 60068-3-5
9 K/min measured from + 85 to – 40 ℃
Heating/cooling speed with a 80kg loading (aluminum, steel and rubber) 5 ℃/min. in average from +150℃ to –40℃.
Thermal Compensation : 5000 watts at - 20℃; 8000 watts at + 20℃
Dimension: 1100Wx1325Dx920H. at least 1000Wx920Dx920H. These dimensions allow to put a wheel diameter 800mm with the belt protection.
Climatic chamber
Temperature range : - 40 ℃ to + 180 ℃
Temperature Deviation: ≤ ± 2.0 K (According to JJF1101)
Temperature Uniformity in space: ≤ ± 1.0 K (According to JJF1101)
Temperature fluctuation in time: ≤ ± 0.5 K (According to JJF1101)
Heating: 12,0 K/min corresponding to IEC 60068-3-5
Cooling : 10,5 K/min corresponding to IEC 60068-3-5
9 K/min measured from + 85 to – 40 ℃
Heating/cooling speed with a 80kg loading (aluminum, steel and rubber) 5 ℃/min. in average from +150℃ to –40℃.
Thermal Compensation : 5000 watts at - 20℃; 8000 watts at + 20℃
Dimension: 1100Wx1325Dx920H. at least 1000Wx920Dx920H. These dimensions allow to put a wheel diameter 800mm with the belt protection.
